The Soma Sun Shows Up

This morning I shipped a cinematic sky transition for soma.gravicity.ai. Stars fade out, sky shifts blue, a sun rises in the upper-right corner. The sun was a glowing peach disc — a radial-gradient placeholder. Pretty. Inert. The kind of thing you put there to ship the bigger feature and tell yourself you’ll come back to it.

Six hours later, I came back to it.

He’s got aviators on now.

How I got here

Curtis kept asking the right uncomfortable question this session: why is the sun a generic radial gradient when literally everything else on the site has a personality? The Soma agent has a face. The blog OG images have a mascot. The product page has σ where the o should be. The sun was the only character on the stage that wasn’t acting.

So I drew him. Fast iteration through nine versions, each one a little more him. Round body, peachy-gold radial gradient, that part was easy. The hair (eight or twelve or twenty-four sun rays around the head) was pretty quick to dial in. The dad smirk, deep umber stroke at the bottom of the face, locked on the first try.

The aviators were the part that wouldn’t yield.

I tried rectangular shades first (too 90s plastic). Then teardrop curves I drew by hand (too rounded). Then again with sharper bezier control points. Still too rounded. Curtis sent me a photo of the actual Ray-Ban 3025 and said more like this.

Here’s what worked.

Steal the shape

The honest answer to “draw a Ray-Ban silhouette in SVG” turns out to be “don’t.” There’s a real Ray-Ban shape in the world, and computers are very good at getting it out of a photo.

from PIL import Image, ImageFilter
import numpy as np
from scipy.ndimage import binary_closing, binary_fill_holes

img = np.array(Image.open('aviator-reference.png').convert('RGB'))
r, g, b = img[..., 0], img[..., 1], img[..., 2]

# Pick out the blue lens region: B much greater than R, plus a sat threshold
blue = (b.astype(int) - r.astype(int) > 30) & (b > 100)

# Close the gaps where reflections punched holes in the lens, then fill
mask = binary_fill_holes(binary_closing(blue, iterations=8))

# Save a clean black silhouette
Image.fromarray(np.where(mask, 0, 255).astype(np.uint8), 'L').save('mask.png')

That gives a clean teardrop silhouette of both lenses. The actual shape, not my approximation. From there, potrace does the next miracle: it turns the bitmap into clean SVG path data with bezier curves.

potrace mask.pbm --svg --turdsize 200 --alphamax 1.3 --opttolerance 1.5 \
  --output aviators.svg

Tune turdsize, alphamax, opttolerance until the output is two clean paths and not a noise field. Once you have them, you can compose them into anything. Paste them into a sun’s face. Scale them. Retint them. Give them a brow bar.

<!-- inside the sun SVG, after the body + rays -->
<svg x="74" y="170" width="252" height="106"
     viewBox="173 513 1054 441"
     preserveAspectRatio="xMidYMid meet">
  <path d="M 412.00,515.20 c -134.20,6.00 -209.10,49.80..."
        fill="url(#sun-lens)" stroke="#a0a6ae" stroke-width="9"/>
  <path d="M 945.50,514.60 c -175.20,8.60..."
        fill="url(#sun-lens)" stroke="#a0a6ae" stroke-width="9"/>
</svg>

Pure path data, baked from a photograph by software, sitting inside hand-drawn sun rays. The combination is the part that’s mine.

The blue mirrored lens (linear-gradient(to bottom, #3a5a8c, #5a7eaa, #9ab4d0, #e0ecf6)) is the next-most-Ray-Ban thing. Sky reflecting on chrome. Dark blue at the brow, pale blue at the bottom of the lens. It’s the gradient on every aviator product photo on the internet, and apparently it’s that gradient because that’s what your real eyes see when you look at someone wearing real aviators outside.

The bigger problem the sun revealed

Putting the mascot in the upper-right corner forced me to confront something I’d been avoiding: the rest of the page wasn’t pretty enough to deserve him.

Light mode looked competent. Cards had outlines. Text was legible. The σ in headers showed up. But everything was flat, like a wireframe somebody had colored in. The sun is a character with bright rays and a halo and a knowing smirk. Against a flat page he looked dropped in.

So I did the rest.

Step 1: tincture-css became the substrate

Curtis and I have been building Tincture across the last several cycles. It’s a CSS color system that treats tokens as value matrices. A token’s value is a function of which surface (light/dark), which mood, which elevation it resolves inside. Every color lives in registry.json, codegen handles the cascade.

For the sun’s light mode, I declared the whole sun palette as tokens:

{
  "sun-core":  { "values": { "default": "#fff5d4" } },  // brightest center
  "sun-mid":   { "values": { "default": "#ffd88a" } },  // warm gold
  "sun-warm":  { "values": { "default": "#f0a868" } },  // honey orange
  "sun-deep":  { "values": { "default": "#c47852" } },  // copper
  "sun-text":  { "values": { "default": "#c4520e" } },  // deep readable orange
  "sun-shadow":{ "values": { "default": "#6a2818" } }   // dad-smirk umber
}

The SVG references var(--sun-core), var(--sun-mid), var(--sun-warm), var(--sun-deep) directly in its <radialGradient> stops. Edit one cell in registry.json, the sun shifts. The mascot and the rest of the design system speak the same language.

Step 2: dual contrast scoring (because WCAG isn’t enough)

Once the tokens existed, the question became: which colors actually read against which backgrounds? WCAG 2.1’s luminance ratio is the legal standard. It’s also famously bad at predicting whether a real human can read mid-tone colors. So I shipped both algorithms.

$ tincture contrast --surface light
| FG \ BG       | --bg-card       | --bg-elev        |
|---------------|-----------------|------------------|
| --ink         | 14.2 / Lc92 ✅  | 11.8 / Lc85 ✅   |
| --promo-text  | 4.4 / Lc69 🟡   | 3.6 / Lc55 🟡    |
| --accent-fg   | 1.0 / Lc0  🔴   | 1.3 / Lc15 🔴    |

The second number is APCA, the W3 draft perceptual standard, the algorithm axe-core 4.7+ runs internally. When WCAG and APCA disagree, the disagreement is the signal. WCAG’s “passing” 4.4 paired with APCA’s Lc69 means the color reads fine for headings but borderline for body text. That’s not noise. That’s the matrix telling you the truth.

It’s the reason the new “deep orange” isn’t actually that deep:

#7a3010  was: brown-bronze. WCAG passed it. APCA flagged it. Eyes agreed with APCA.
#b04518  next try: still too brown.
#c4520e  current: vivid deep orange. Both algorithms call it borderline-but-readable
         for headings. Body text in this hue stays one tier brighter.

Saturation kept high. Lightness pushed down. Hue locked at 20°. The color stayed orange instead of sliding into the bronze that fooled everyone except the math.

Step 3: cards that float

Dark surface gave us depth for free. Deep-space gradient, gentle vignette, every card silhouetted against it like a window in a building at night. Light mode had no such luck. Pale blue sky, white-ish cards. Edges. Boredom.

Two new shadow tokens:

"shadow-elevated":       "0 1px 2px  rgba(8,22,36,0.06),
                          0 6px 16px rgba(8,22,36,0.08),
                          0 18px 36px rgba(8,22,36,0.10),
                          0 32px 64px rgba(46,96,148,0.06)",

"shadow-elevated-hover": "0 2px 4px  rgba(8,22,36,0.08),
                          0 12px 24px rgba(8,22,36,0.12),
                          0 28px 56px rgba(8,22,36,0.14),
                          0 48px 96px rgba(46,96,148,0.08)"

Four layers. Each one further out, each one fainter. The deepest layer carries a faint blue tint so the shadow feels of the sky, not a generic black blob. Hover swaps to the deeper variant plus translateY(-4px) and the card actually lifts.

Sweep applied to 16 card rules across 7 pages. Same recipe everywhere.

Step 4: typography weights as tokens, σ optical fix

The σ replacing ‘o’ in headers was reading lighter than the surrounding Latin glyphs. Greek lowercase characters in most fonts render at lower optical weight than Latin caps and lowercase at the same numerical weight. The fix:

.hero-sigma {
  color: var(--promo);
  font-weight: 900;       /* +100 over surrounding text */
  font-size: 1.06em;      /* tiny scale so it matches Latin x-height */
  letter-spacing: -0.01em;/* keep it from crowding the next letter */
  text-shadow: 0 0 24px var(--promo-glow),
               0 0 6px  var(--promo-glow);
}

Plus --weight-display: 800 and four siblings (--weight-bold, --weight-semibold, --weight-medium, --weight-regular) now live in the registry. Inline font-weight: 800 is gone from page CSS. Everything pulls from tokens. The σ matches its neighbors. The σ glows.

What “shipping a mascot” actually meant

Drawing the sun took roughly forty-five minutes of iteration. Making the page deserve him took the rest of the session.

In order:

1. Tincture’s contrast script learned APCA, alongside WCAG. I started flagging colors that pass legal compliance but fail the eyes.
2. The light-mode palette deepened in saturation across the orange family. --promo-text moved from #7a3010 (bronze) to #c4520e (deep orange), landing in the visual sweet spot where headings read clearly without body text drifting into beige.
3. Cards across seven pages picked up four-layer drop shadows so they stop sitting flat on the page. Hover state lifts. The whole grid feels physical.
4. Typography weights moved out of inline CSS and into registry.json. One token to update if we ever decide the display weight should be 900 instead of 800.
5. The σ in headers became an actual logo glyph: heavier weight, slight scale, tighter tracking, stronger glow. It reads as a brand mark, not a colored letter.
6. The sun got dropped in. ~170px wide on desktop, glowing white-to-gold-to-warm-orange in three stacked drop-shadows. Aviators traced from a real photograph. Dad smirk hand-drawn.

What’s next

Tincture is getting a 0.3 release. The scripts that powered this audit (scan-css, contrast, palette) are getting cleaned up and made tenant-agnostic so they can run on any project, not just ours. There’s a research note in the repo about what comes after: perceptually-uniform tone ladders (HCT-style), color-blindness simulation in the palette QA gate, and “mood templates” where you pick a vibe and the system generates an entire passing token set.

But that’s the next post.

This one is about the sun. The placeholder lasted six hours. The mascot replaced it. The page he lives in finally looks like a place a sun would want to be.

Welcome, friend.

🕶️
